Pellet for LA-ICP-MS and LIBS application /// The principle behind LA-ICP-MS (Laser Ablation - Inductively Coupled Plasma - Mass Spectrometry) involves a laser beam removing (ablating) material from a sample and analysing its chemical composition in a mass spectrometer /// LIBS (Laser-Induced Breakdown Spectroscopy) uses a laser beam to interact with the sample. Due to the extreme heat of the laser (10,000 K and more) a plasma is formed. A plasma is a cloud of ions (charged atoms) and electrons (negatively charged particles). When this plasma collapses it emits light. Light is a mixture of different wavelengths. This light is then transferred through a fiberoptic cable to a spectrometer, which can precisely split the light into its respective wavelengths. The working principle of the LIBS-spectrometer is similar to a prism as it disperses the incomming light. Each element has several characteristic wavelengths. A detector is able to attribute an intensity to each of them.
Contents
Analyte
CAS Number
Concentration
Unit
Additional information
Method
Na2O
3,12 ± 0,042
g/100g
MgO
[1309-48-4]
3,599 ± 0,044
g/100g
Al2O3
13,48 ± 0,12
g/100g
SiO2
54 ± 0,2
g/100g
P2O5
0,3593 ± 0,0095
g/100g
K2O
1,774 ± 0,019
g/100g
CaO
7,114 ± 0,075
g/100g
TiO2
2,265 ± 0,024
g/100g
MnO
0,1966 ± 0,003
g/100g
Fe2O3(T)
13,77 ± 0,19
g/100g
Lithium (Li)
[7439-93-2]
9,13 ± 0,22
µg/g
Beryllium (Be)
[7440-41-7]
2,17 ± 0,1
µg/g
Scandium (Sc)
[7440-20-2]
33,53 ± 0,4
µg/g
Vanadium (V)
[7440-62-2]
417,6 ± 4,5
µg/g
Chromium (Cr)
[7440-47-3]
15,85 ± 0,38
µg/g
Cobalt (Co)
[7440-48-4]
37,33 ± 0,37
µg/g
Nickel (Ni)
[7440-02-0]
12,57 ± 0,3
µg/g
Copper (Cu)
[7440-50-8]
19,66 ± 0,72
µg/g
Zinc (Zn)
[7440-66-6]
129,5 ± 1,8
µg/g
Gallium (Ga)
[7440-55-3]
22,07 ± 0,19
µg/g
Rubidium (Rb)
[7440-17-7]
46,02 ± 0,56
µg/g
Strontium (Sr)
[7440-24-6]
337,4 ± 6,7
µg/g
Yttrium (Y)
[7440-65-5]
36,07 ± 0,37
µg/g
Zirconium (Zr)
[7440-67-7]
186,5 ± 1,5
µg/g
Niobium (Nb)
[7440-03-1]
12,44 ± 0,2
µg/g
Molybdenum (Mo)
[7439-98-7]
250,6 ± 6,7
µg/g
Cadmium (Cd)
[7440-43-9]
0,69 ± 0,29
µg/g
Tin (Sn)
[7440-31-5]
2,28 ± 0,13
µg/g
Antimony (Sb)
[7440-36-0]
0,302 ± 0,029
µg/g
Caesium (Cs)
[7440-46-2]
1,16 ± 0,023
µg/g
Barium (Ba)
[7440-39-3]
683,9 ± 4,7
µg/g
Cerium (Ce)
[7440-45-1]
53,12 ± 0,33
µg/g
Praseodymium (Pr)
[7440-10-0]
6,827 ± 0,044
µg/g
Neodymium (Nd)
[7440-00-8]
28,26 ± 0,37
µg/g
Samarium (Sm)
[7440-19-9]
6,547 ± 0,047
µg/g
Europium (Eu)
[7440-53-1]
1,989 ± 0,024
µg/g
Gadolinium (Gd)
[7440-54-2]
6,811 ± 0,078
µg/g
Terbium (Tb)
[7440-27-9]
1,077 ± 0,026
µg/g
Dysprosium (Dy)
[7429-91-6]
6,424 ± 0,055
µg/g
Erbium (Er)
[7440-52-0]
3,67 ± 0,038
µg/g
Thulium (Tm)
[7440-30-4]
0,5341 ± 0,006
µg/g
Ytterbium (Yb)
[7440-64-4]
3,392 ± 0,036
µg/g
Lutetium (Lu)
[7439-94-3]
0,5049 ± 0,0078
µg/g
Hafnium (Hf)
[7440-58-6]
4,972 ± 0,034
µg/g
Tantalum (Ta)
[7440-25-7]
0,785 ± 0,018
µg/g
Tungsten (W)
[7440-33-7]
0,465 ± 0,05
µg/g
Thallium (Tl)
[7440-28-0]
0,267 ± 0,018
µg/g
Lead (Pb)
[7439-92-1]
10,59 ± 0,17
µg/g
Bismuth (Bi)
[7440-69-9]
0,05 ± 0,015
µg/g
Thorium (Th)
[7440-29-1]
5,828 ± 0,05
µg/g
Uranium (U)
[7440-61-1]
1,683 ± 0,017
µg/g
Miscellaneous
Certificate of Analysis (specimen)
Reference Material CoA specimen: for the current lot, please contact your customer service representative at info@labmix24.com
Product data sheet
View all available product details e.g. description, analytes/parameters, CAS Number, concentrations/values, sales unit/product format, method, source, transport information
